Wire Crimping Machine
>
|
| Place of Origin | China |
| Brand Name | RKENS |
| Model Number | RS-5505S |
Automatic 5 wire cutting, stripping and two-ends crimping machine
RS-5505S is automatic wire cutting stripping and crimping machine . It can cut wires, strip wires and crimping two-ends. Cutting stripping and crimping can be finished with one machine.
Also it can cut, strip 5 wires one time.
This wire cutting stripping and crimping machien is for 14 AWG to 32 AWG stranded electric wire. The terminal should be on tape and reel, both horizontal or vertial type are OK.
| Name | Full automatic cutting stripping, two-ends crimping machine |
| Uage | Cut, strip, and double-end pressing terminals |
| Power | AV 220V 50/60Hz less than 2000w |
| Production rate | 3000pcs/h Length=40mm |
| Applicable wire | AWG14~AWG32 |
| Applicable wire | 45~99999mm |
| Tool material |
tungsten steel
|
| Applicable terminal | Straight, horizonal terminal |
| Crimping force | 2.0 Ton |
| Detector | detect terminal crimping, wire detect |
| Wire adjustment | support adjust |
| Size | 1060Wx800LX1330H MM |
| Weight | About 460KG |
